Addressing
T
he safety laser scanner needs a unique IP address, the sub-network mask and,
possibly, the IP address of the router to be able to exchange data with other devices in
the network.
The safety laser scanner also requires a PROFINET name.
As long as no configuration has been transferred to the device, you can change the
network settings via a network connection without logging in to the device.
Options for assigning the data to the safety laser scanner:
•
In Safety Designer in the Addressing dialog
•
With a configuration software for PROFINET networks
•
With a PROFINET control unit
If you store the IP address remanently, it is retained even after switching the system off
and on again. It can be changed, however, from the PROFINET control unit.
4.5.4 Configuring control
Overview
Y
ou will find information below on entries in the configuration software for the control
unit.
Information about the configuration of the safety laser scanner see "Configuration",
page 85.
Important information
NOTE
A
t www.sick.com, you’ll find the latest GSDML file for integrating the safety laser
scanner in the control unit.
Approach
1.
Import the GSDML file to the control unit’s configuration software.
2. Search the hardware catalog to find the desired device, e.g. use the search func‐
tion and enter “SICK” or “microScan3”.
3. Add the device to the project and connect to the control unit.
4. To use a different process image, select a different module, if necessary.
5. Assign PROFINET names.
6. Set the PROFIsafe parameters in the submodule.
Table 4: PROFIsafe parameters
Parameter Meaning Setting
F_SIL Safety integrity level (NoSIL,
SIL1 or SIL2) of t
he safety
laser scanner
Depends on application
F_CRC_Length PROFIsafe data integrity
assurance
Depends on the process
image used:
•
3 bytes for PROFIsafe
V2.4
•
4 bytes for PROFIsafe
V2.6.1
PROJECT PLANNING 4
8021219/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET
67
Subject to change without notice
