SICK microScan3 User Manual

1
2
3
112
Ø 99,5
163,1
201,6
≤ 200
44
12
47,175,9 40,1
≥ 25
≥ 25
111,1
149,1
85
22 36,164,9
M5×7,5
Figure 99: Dimensional drawing (devices with SCRJ connection)
1
2
3
112
Ø 99,5
≤ 200
M5×7,5
8544
12
150,8
111,1
47,1
63,6
40,1
≥ 25
≥ 25
22 36,152,6
173,7
132
Figure 100: Dimensional drawing (devices with M12 connection)
All dimensions in mm.
1
Mirror rotational axis
2
Scan plane
3
Required viewing slit
13 TECHNICAL DATA
188
O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET 8021219/1ELL/2022-01-21 | SICK
Subject to change without notice

SICK microScan3 Specifications

General

Scanning angle	275°
Power supply	24 V DC
Supply voltage	24 V DC ± 20%
Enclosure rating	IP65
Resolution	70 mm
Protective field range	5.5 m
Number of fields	128
Interface	Ethernet
Safety integrity level	SIL3
Performance level	PL e
Ambient temperature	+50°C
Scanning range	5.5 m
