SICK microScan3 User Manual

Integration in
t
he control
Connection type Protective field
range
Position of the
system plug
when delivered
Type code Part number
PROFINET
PROFIsafe
RJ45, for push-pull
male connector
(copper)
≤ 5.5 m Bottom MICS3-CCAZ55PZ1P01 1100392
PROFINET
P
ROFIsafe
RJ45, for push-pull
male connector
(copper)
≤ 9.0 m Bottom MICS3-CCAZ90PZ1P01 1100394
PROFINET
PROFIsafe
SCRJ, for push-pull
male connector
(optical fibers)
≤ 4.0 m Bottom MICS3-CCAZ40LZ1P01 1100398
PROFINET
P
ROFIsafe
SCRJ, for push-pull
male connector
(optical fibers)
≤ 5.5 m Bottom MICS3-CCAZ55LZ1P01 1100400
PROFINET
PROFIsafe
SCRJ, for push-pull
male connector
(optical fibers)
≤ 9.0 m Bottom MICS3-CCAZ90LZ1P01 1100402
PROFINET
PROFIsafe
M12, 4-pin, D-
coded
≤ 4.0 m Bottom MICS3-CBAZ40PZ1P01 1092720
PROFINET
P
ROFIsafe
M12, 4-pin, D-
coded
≤ 5.5 m Bottom MICS3-CBAZ55PZ1P01 1092721
PROFINET
PROFIsafe
M12, 4-pin, D-
coded
≤ 5.5 m Rear MICS3-CBAZ55PZ1P03 1102629
PROFINET
PROFIsafe
M12, 4-pin, D-
coded
≤ 9.0 m Bottom MICS3-CBAZ90PZ1P01 1094463
PROFINET
P
ROFIsafe
M12, 4-pin, D-
coded
≤ 9.0 m Rear MICS3-CBAZ90PZ1P03 1102630
14 ORDERING INFORMATION
190
O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET 8021219/1ELL/2022-01-21 | SICK
Subject to change without notice

SICK microScan3 Specifications

General

Scanning angle	275°
Power supply	24 V DC
Supply voltage	24 V DC ± 20%
Enclosure rating	IP65
Resolution	70 mm
Protective field range	5.5 m
Number of fields	128
Interface	Ethernet
Safety integrity level	SIL3
Performance level	PL e
Ambient temperature	+50°C
Scanning range	5.5 m
