Bit Description
Byte 4 4.0 Reserved
4.1 Reserved
4.2 Reserved
4.3 Reserved
4.4 Reserved
4.5 Reserved
4.6 Reserved
4.7 Reserved
Byte 5 5.0 Reserved
5.1 Reserved
5.2 Reserved
5.3 Reserved
5.4 Reserved
5.5 Reserved
5.6 Reserved
5.7 Reserved
OUTPUT
T
able 24: Process image S3000 PROFINET IO/IO-OF Advanced OUTPUT
Bit Description
Byte 0 0.0 Monitoring case switching A1
0.1 Monitoring case switching A2
0.2 Monitoring case switching B1
0.3 Monitoring case switching B2
0.4 Reserved
0.5 Reserved
0.6 Reserved
0.7 Reserved
Byte 1 1.0 Reset the protective field
1.1 Reserved
1.2 Reset the simultaneous protective field
1.3 Reserved
1.4 Standby
1.5 Initialization
1.6 Reserved
1.7 Reserved
Byte 2 2.0 Reserved
2.1 Reserved
2.2 Reserved
2.3 Reserved
2.4 Reserved
2.5 Reserved
2.6 Reserved
2.7 Reserved
TECHNICAL DATA 12
8013291/ZA19/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF
107
Subject to change without notice
