Maximum protective field range
50 mm (leg detection) 3.30 m 4.80 m
70 mm (leg detection) 4.70 m 7.00 m
150 mm (body detection)
1)
7.00 m 7.00 m
1)
Cannot be configured for mobile applications.
Complementary information
NOTE
Y
ou can configure the warning field up to 49 m for all resolutions. The detection capa‐
bility within the warning field depends on the radiance factor of the objects to be
detected.
Further topics
•
"Characteristic curves", page 117
7.8.2 Basic response time
The basic response time depends on the angular resolution selected and is:
•
60 ms ba
sic response time at 0.5° angular resolution
•
120 ms basic response time at 0.25° angular resolution
7.8.3 Angular resolution and maximum protective field range
The angular resolution affects the maximum protective field range and the basic
r
esponse time.
Two angular resolutions can be configured:
•
At 0.5° angular resolution the basic response time is 60 ms.
•
At 0.25° angular resolution the basic response time is 120 ms.
NOTE
•
T
he maximum protective field range of the safety laser scanner must be sufficient
to cover the calculated protective field size including the necessary supplements.
Further topics
•
"R
esolution", page 75
•
"Basic response time", page 76
•
"Protective field size", page 37
7.9 Restart
Overview
Y
ou can configure the restart behavior as follows:
•
Without restart interlock
•
With restart delay
•
With restart interlock
The type of restart can be configured in the CDS.
7 C
ONFIGURATION
76
O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF 8013291/ZA19/2019-11-14 | SICK
Subject to change without notice
