12 Technical data
12.1 Process image S3000 PROFINET IO/IO-OF Advanced
The process contains data on four monitoring cases and four field sets.
INPUT
T
able 23: Process image S3000 PROFINET IO/IO-OF Advanced INPUT
Bit Description
Byte 0 0.0 Protective field clear
0.1 Warning field clear
0.2 Simultaneous protective field clear
0.3 Simultaneous warning field clear
0.4 Reset required (protective field)
0.5 Reserved
0.6 Reset required (simultaneous protective field)
0.7 Reserved
Byte 1 1.0 Contamination
1.1 Monitoring case valid
1.2 Monitoring case number – Bit 0
1.3 Monitoring case number – Bit 1
1.4 Reserved
1.5 Reserved
1.6 Reserved
1.7 Reserved
Byte 2 2.0 Reserved
2.1 Reserved
2.2 Reserved
2.3 Reserved
2.4 Reserved
2.5 Reserved
2.6 Reserved
2.7 Reserved
Byte 3 3.0 Reserved
3.1 Reserved
3.2 Reserved
3.3 Reserved
3.4 Reserved
3.5 Reserved
3.6 Reserved
3.7 Reserved
12 TECHNICAL DATA
106
O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF 8013291/ZA19/2019-11-14 | SICK
Subject to change without notice
