SICK S3000 PROFINET IO User Manual

Bit Description
Byte 3 3.0 Reserved
3.1 Reserved
3.2 Reserved
3.3 Reserved
3.4 Reserved
3.5 Reserved
3.6 Reserved
3.7 Reserved
Byte 4 4.0 Reserved
4.1 Reserved
4.2 Reserved
4.3 Reserved
4.4 Reserved
4.5 Reserved
4.6 Reserved
4.7 Reserved
Byte 5 5.0 Reserved
5.1 Reserved
5.2 Reserved
5.3 Reserved
5.4 Reserved
5.5 Reserved
5.6 Reserved
5.7 Reserved
12.2 Process image S3000 PROFINET IO/IO-OF Professional
The process contains data on eight monitoring cases and eight field sets.
INPUT
T
able 25: Process image S3000 PROFINET IO/IO-OF Professional INPUT
Bit Description
Byte 0 0.0 Protective field clear
0.1 Warning field clear
0.2 Simultaneous protective field clear
0.3 Simultaneous warning field clear
0.4 Reset required (protective field)
0.5 Reserved
0.6 Reset required (simultaneous protective field)
0.7 Reserved
12 TECHNICAL DATA
108
O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF 8013291/ZA19/2019-11-14 | SICK
Subject to change without notice
