Table 16: Recommended multiple sampling
Recommended multiple sampling
Application Basic response time
60 ms
Basic response time
120 ms
Stationary under clean ambient con‐
dit
ions
2× 2×
Vertical applications 3 times –
Mobile 4 times 4 times
Stationary under dusty ambient con‐
dit
ions
8 times 8 times
NOTE
•
Usin
g multiple sampling you can increase the availability of a system.
•
The multiple sampling can be configured in the CDS. A specific multiple sampling
value can be set both for the configured field set and for the simultaneous field
set in each monitoring case.
Further topics
•
"R
esponse times", page 120
7.11.3 Simultaneous monitoring
Overview
Usin
g simultaneous monitoring, the S3000 can monitor two field sets at the same time
(e.g., a hazardous area on the left and a hazardous area on the right) within a monitor‐
ing case.
Approach
1. On the Cases tab, select a further field set as a simultaneous field set within the
relevant monitoring case.
7.11.4 Checking the monitoring case switching
To check the switching between monitoring cases, configure a series of monitoring
c
ases. Either an arbitrary sequence, a unique sequence, or two alternative sequences
can be defined.
•
Arbitrary sequence: It is allowed to switch from one monitoring case to any other
defined monitoring case.
•
Unique sequence: It is only allowed to switch from a monitoring case to another
specifically defined monitoring case.
•
Alternative sequence: It is allowed to switch from a monitoring case to one of two
specifically defined monitoring cases.
NOTE
Use the monitoring case switching check as an additional check on the control. For
example, to detect deviations of a vehicle from a corridor, or deviations of a system
from the prescribed production process.
Figure 66: Schematic representation of monitoring case switching - arbitrary sequence
7 CONFIGURATION
86
O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF 8013291/ZA19/2019-11-14 | SICK
Subject to change without notice

SICK S3000 PROFINET IO Specifications

General

Field of view	190°
Response time	8 ms ... 80 ms
Protection class	IP65
Number of simultaneously monitored fields	4
Scanning angle	190°
Number of inputs	2
Number of outputs	4
Angular Resolution	0.5°
Interfaces	PROFINET IO
Operating temperature	0 °C ... +50 °C
Resolution for object detection	30 mm
Supply voltage	24 V DC
Type	Laser Scanner
Operating Voltage	24 V DC
Ambient Temperature	0 °C ... +50 °C
Storage Temperature	–25 °C ... +70 °C
Protective field range	0.2 m to 3 m
Protection Field Range	0.2 m to 3 m
