SICK S3000 PROFINET IO User Manual

OUTPUT
T
able 26: Process image S3000 PROFINET IO/IO-OF Professional OUTPUT
Bit Description
Byte 0 0.0 Monitoring case switching A1
0.1 Monitoring case switching A2
0.2 Monitoring case switching B1
0.3 Monitoring case switching B2
0.4 Monitoring case switching C1
0.5 Monitoring case switching C2
0.6 Monitoring case switching D1
0.7 Monitoring case switching D2
Byte 1 1.0 Reset the protective field
1.1 Reserved
1.2 Reset the simultaneous protective field
1.3 Reserved
1.4 Standby
1.5 Initialization
1.6 Reserved
1.7 Reserved
Byte 2 2.0 Reserved
2.1 Reserved
2.2 Reserved
2.3 Reserved
2.4 Reserved
2.5 Reserved
2.6 Reserved
2.7 Reserved
Byte 3 3.0 Reserved
3.1 Reserved
3.2 Reserved
3.3 Reserved
3.4 Reserved
3.5 Reserved
3.6 Reserved
3.7 Reserved
Byte 4 4.0 Reserved
4.1 Reserved
4.2 Reserved
4.3 Reserved
4.4 Reserved
4.5 Reserved
4.6 Reserved
4.7 Reserved
12 TECHNICAL DATA
110
O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF 8013291/ZA19/2019-11-14 | SICK
Subject to change without notice

SICK S3000 PROFINET IO Specifications

General

Field of view	190°
Response time	8 ms ... 80 ms
Protection class	IP65
Number of simultaneously monitored fields	4
Scanning angle	190°
Number of inputs	2
Number of outputs	4
Angular Resolution	0.5°
Interfaces	PROFINET IO
Operating temperature	0 °C ... +50 °C
Resolution for object detection	30 mm
Supply voltage	24 V DC
Type	Laser Scanner
Operating Voltage	24 V DC
Ambient Temperature	0 °C ... +50 °C
Storage Temperature	–25 °C ... +70 °C
Protective field range	0.2 m to 3 m
Protection Field Range	0.2 m to 3 m
