SICK S3000 PROFINET IO User Manual

2)
SELV/PELV safety extra-low voltage.
3)
Without overrun of cable glands with a mounted system plug.
Functional information
T
able 28: Functional information
Minimum Typical Maximum
Resolution 30 mm, 40 mm, 50 mm, 70 mm,
150 mm
Protective field of the sensor head with 4.0 m scanning range
1)
a
t 120 ms response time
At 30 mm resolution 2.80 m
At 40 mm resolution 3.80 m
At 50 mm resolution 4.00 m
At 70 mm resolution 4.00 m
At 150 mm resolution 4.00 m
Protective field of the sensor head with 4.0 m scanning range at 60 ms response time
At 30 mm resolution 1.90 m
At 40 mm resolution 2.60 m
At 50 mm resolution 3.30 m
At 70 mm resolution 4.00 m
At 150 mm resolution 4.00 m
Protective field of the sensor head with 5.5 m scanning range at 120 ms response time
At 30 mm resolution 2.80 m
At 40 mm resolution 3.80 m
At 50 mm resolution 4.80 m
At 70 mm resolution 5.50 m
At 150 mm resolution 5.50 m
Protective field of the sensor head with 5.5 m scanning range at 60 ms response time
At 30 mm resolution 1.90 m
At 40 mm resolution 2.60 m
At 50 mm resolution 3.30 m
At 70 mm resolution 4.70 m
At 150 mm resolution 5.50 m
Protective field of the sensor head with 7 m scanning range at 120 ms response time
At 30 mm resolution 2.80 m
At 40 mm resolution 3.80 m
At 50 mm resolution 4.80 m
At 70 mm resolution 7.00 m
At 150 mm resolution 7.00 m
Protective field of the sensor head with 7 m scanning range at 60 ms response time
At 30 mm resolution 1.90 m
At 40 mm resolution 2.60 m
At 50 mm resolution 3.30 m
At 70 mm resolution 4.70 m
At 150 mm resolution 7.00 m
TECHNICAL DATA 12
8013291/ZA19/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF
113
Subject to change without notice

SICK S3000 PROFINET IO Specifications

General

Field of view	190°
Response time	8 ms ... 80 ms
Protection class	IP65
Number of simultaneously monitored fields	4
Scanning angle	190°
Number of inputs	2
Number of outputs	4
Angular Resolution	0.5°
Interfaces	PROFINET IO
Operating temperature	0 °C ... +50 °C
Resolution for object detection	30 mm
Supply voltage	24 V DC
Type	Laser Scanner
Operating Voltage	24 V DC
Ambient Temperature	0 °C ... +50 °C
Storage Temperature	–25 °C ... +70 °C
Protective field range	0.2 m to 3 m
Protection Field Range	0.2 m to 3 m
