NOTE
If t
he protective field 3 or the warning fields 2 extend all the way to a wall or another
object (pillar, neighboring machine, shelf), there should be a distance of 100 mm
between the protective field or warning field and the object to prevent false triggering
1.
Figure 62: Configuring the protective field and warning field
DANGER
P
ersons or parts of the body to be protected may not be recognized or not recognized in
time in case of non-observance.
If it is possible to access a narrow strip between the protective field and a wall or
another object, this strip must be protected using additional measures (e.g., fence or
floor protection).
b
Secure unprotected areas.
Further topics
•
"R
esolution", page 75
7.10.2 Importing and exporting field sets and fields
Overview
If y
ou need identical field sets or fields across different projects, you can export entire
field sets or individual fields out of one project and import them into another project.
Importing field sets and fields
1. Click on Import field sets from XML file.
2. Select exported file with field set information.
✓
A preview of the field sets and fields saved in the file will be shown.
3. Select the required field sets and import fully.
4. Drag individual fields into the required field set.
✓
The field sets and fields will be imported.
7 C
ONFIGURATION
80
O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF 8013291/ZA19/2019-11-14 | SICK
Subject to change without notice
