SICK S3000 PROFINET IO User Manual

5.2 Mounting procedure
Overview
T
he origin of the scan plane is located 63 mm above the bottom edge of the device.
When the device is mounted using mounting kit 3, the origin of the scan plane is
located 102 mm above the bottom edge of mounting kit 3.
The device can be mounted in the following ways:
•
Direct mounting without mounting kit
•
Mounting using mounting kit 1
•
Mounting using mounting kits 1 and 2
•
Mounting using mounting kits 1, 2 and 3
The mounting kits build one on another. To mount the device using mounting kit 2, you
will therefore also need mounting kit 1. To mount the device using mounting kit 3, you
will also need mounting kits 1 and 2.
The installation orientation of the safety laser scanner is not crucial, i.e., the device can
be mounted both at an angle or upside down.
Important information
WARNING
Ine
ffectiveness of the protective device
Persons or parts of the body to be protected may not be recognized or not recognized in
time in case of non-observance.
b
Make sure that the field of view of the device is not restricted.
WARNING
Ine
ffectiveness of the protective device
Persons or parts of the body to be protected may not be recognized or not recognized in
time in case of non-observance.
b
Prevent people from being able to crawl beneath, stand behind, or climb over the
protective field by mounting the device appropriately.
MOUNTING 5
8013291/ZA19/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF
51
Subject to change without notice
