SICK S3000 PROFINET IO User Manual

Minimum Typical Maximum
Scanning angle 190°
(–5° t
o
+185°)
Radiance factor 1.8% Several
1,000%
(r
eflectors)
Angular resolution 0.5° 0.25°
Generally necessary protective field supplement 100 mm
Supplement for retro-reflectors on scan plane with
dis
tance of less than 1 m to protective field bound‐
ary
200 mm
Measurement error for measurement data output up to 5.5 m and 1.8% radiance factor
Systematic error ± 5 mm
Statistical including systematic error
At 1 σ ± 24 mm
At 2 σ ± 43 mm
At 3 σ ± 62 mm
At 4 σ ± 80 mm
At 5 σ ± 99 mm
Flatness of the scan field at 5.5 m ± 70 mm
Flatness of the scan field at 7 m ± 88 mm
Distance of mirror rotational axis (zero point of X-
and Y
-axis) to rear side of device
93 mm
Distance between center point of scan plane and
bo
ttom edge of the housing
63 mm
Warning field range (radial) Approx. 20
m
2)
49 m
Distance measurement range 49 m
Number of multiple samplings (can be configured
v
ia CDS)
2 16
Power-up delay 9 s 20 s
Restart after (can be configured) 2 s 60 s
1)
Radial distance to the safety laser scanner.
2)
For objects with 20% radiance factor.
Electric
T
able 29: Electric
Minimum Typical Maximum
Electrical protection class III (VDE 0106, EN 60950)
Bus connection 2 standard PROFINET IO female connec‐
t
ors for push-pull plug connectors with
metal housing (RJ-45 or SCRJ)
Levels for input information
Restart
1)
Activated on low-high transition
Initialization Activated on low-high transition
Standby Activated on permanently high
Monitoring case switching
1)
Static (complementary)
12 TECHNICAL DATA
114
O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF 8013291/ZA19/2019-11-14 | SICK
Subject to change without notice
