Minimum Typical Maximum
Supply voltage (SELV)
2)
3)
16.8 V 24 V 28.8 V
Permissible residual ripple
4)
± 5%
Start-up current
5)
2 A
Operating current without output load
6)
0.6 A 0.8 A
Operating current with maximum output load
6)
2.2 A 2.3 A
Power consumption without output load
6)
14 W 19 W
Power consumption with maximum output load
6)
53 W 55 W
Power consumption in standby mode or park mode
without output load
14 W 19 W
Electrical connection Plug-in device connection plug:
•
Cable gland for cable diameter of
5 mm … 10 mm
•
Screw terminal connection for maxi‐
mum wire cross-section 1.5 mm²
•
Integrated configuration memory
Screw terminal technical data
Rigid wire cross-circuit 0.14 mm² 1.5 mm²
Flexible wire cross-circuit
7)
0.14 mm² 1.0 mm²
American wire gage (AWG) 26 16
Wire stripping length 5 mm
Screw tightening torque 0.22 Nm 0.25 Nm
Cable length for power supply tolerance ± 10%
At wire cross-section 1 mm² 50 m
with a wire cross-section of 0.5 mm² 25 m
with a wire cross-section of 0.25 mm² 12 m
Cable length for power supply tolerance ± 5%
At wire cross-section 1 mm² 60 m
with a wire cross-section of 0.5 mm² 30 m
with a wire cross-section of 0.25 mm² 15 m
Cable length for power supply tolerance ± 1%
At wire cross-section 1 mm² 70 m
with a wire cross-section of 0.5 mm² 35 m
with a wire cross-section of 0.25 mm² 17 m
Configuration and diagnostic interface
Communication protocol RS232 (proprietary)
Transmission rate 9,600 Baud
19,200 Baud
38,400 Baud
Cable length for 9,600 Baud and 0.25 mm²
c
ables
15 m
Galvanic separation No
Output TxD HIGH 5 V 15 V
Output TxD LOW –15 V –5 V
Voltage range RxD –15 V 15 V
Switching threshold RxD LOW –15 V 0.4 V
Switching threshold RxD HIGH 2.4 V 15 V
TECHNICAL DATA 12
8013291/ZA19/2019-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF
115
Subject to change without notice
