Parameter Meaning Setting
F_WD_Time Monitoring time (“Watchdog time”) for the cyclic service.
If no v
alid PROFIsafe telegram is exchanged between the
S3000 PROFINET IO/IO-OF and the FPLC within the set
monitoring time, both will proceed to the safe status, i.e.,
they assign themselves failsafe values.
The monitoring time should be sufficiently long to toler‐
ate minor delays in communication. In the event of an
error however, it must not unnecessarily delay the sys‐
tem response of the S3000 PROFINET IO/IO-OF or that
of the FPLC.
From 1 to
65,535 ms,
depending on the
application
1)
Cannot be changed.
Further topics
•
"Setting the PROFIsafe address on the S3000 PROFINET IO/IO-OF", page 72
7.6.1 Setting the PROFIsafe address on the S3000 PROFINET IO/IO-OF
Overview
T
o be able to operate the device as a PROFIsafe user, it must have a PROFIsafe
address. The PROFIsafe address must match the corresponding setting in the FPLC net‐
work engineering tool.
Approach
1. Open the PROFIBUS configuration for the bus node in the network engineering
tool.
2. Read the value of the F_Dest_Add parameter.
3. In the CDS, navigate through the following path: device symbol S3000 PROFINET IO,
in the context menu Configuration draft, Edit, General tab, PROFIsafe address
(F_Dest_Add) option.
4. Use the CDS to set the value read as the PROFIsafe address in the configuration
for the S3000.
7 C
ONFIGURATION
72
O P E R A T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF 8013291/ZA19/2019-11-14 | SICK
Subject to change without notice
