Setting the address
Set the address of the PROFIBUS slave.
Setting the address (Page 143)
Setting the telegram
Set the telegram in the inverter as in the PROFIBUS master. Interconnect the telegrams in the
control program of the PROFIBUS master with the signals of your choosing.
Drive control via PROFIBUS or PROFINET (Page 217)
Application examples
You can find application examples for PROFIBUS communication on the Internet:
Controlling the speed of a SINAMICS G110M/G120/G120C/G120D with S7-300/400F via
PROFINET, with Safety Integrated (via terminal) and HMI (https://
support.industry.siemens.com/cs/ww/en/view/60441457)
Controlling the speed of a SINAMICS G110M/G120 (Startdrive) with S7-1500 (TO) via
PROFINET, with Safety Integrated (via terminal) and HMI (https://
support.industry.siemens.com/cs/ww/en/view/78788716)
4.5.11.3 Installing the GSD
Procedure
To install the GSD of the inverter in the engineering system of the controller, proceed as follows:
1. Save the GSD on your PC via one of the following methods.
– From the Internet:
GSD (http://support.automation.siemens.com/WW/view/en/22339653/133100)
– From your inverter:
Insert a memory card into the inverter and then set p0804 = 12.
The inverter writes the GSD as zipped file (*.zip) into directory /SIEMENS/SINAMICS/
DATA/CFG on the memory card.
2. Unzip the GSD file on your computer.
3. Import the GSD in the engineering system of the controller.
You have now installed the GSD file in the engineering system of the controller.


Installing
4.5 Connecting the interfaces for the inverter control
Converter with the CU230P-2 Control Units
142 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
