Changes in the current manual
Notable changes since Edition 01/2017
New hardware
● Operator Panel IOP replaced by Intelligent Operator Panel 2 (IOP-2).
Tools to commission the inverter (Page 146)
Installing Power Modules (Page 64)
● New PM240‑2 Power Modules in push-through technology, FSD … FSF - for 200 V, 400 V
and 690 V
Power Module (Page 34)
Technical data, PM240-2 Power Module (Page 476)
New functions
● Expansion of the technology controller to include the following functions:
– Gain K
P
and integral time T
N
can be adapted.
– The control deviation can be used as adaptation signal.
PID technology controller (Page 274)
● Improved method for optimizing the efficiency of standard induction motors
Efficiency optimization (Page 348)
● DC Link formation with the PM330 power module
Forming DC link capacitors (Page 149)
● The inverter issues an alarm if a memory card is not inserted.
Activate message for a memory card that is not inserted (Page 380)
Overview of all new and modified functions in firmware V4.7 SP9:
Firmware version 4.7 SP9 (Page 515)
Corrections
● Default 14 of the terminal strip corrected:
The higher-level control switches the function of the terminal strip via PZD01, bit 15 (not
via digital input DI 3).
Default setting of the interfaces (Page 115)
● The compound braking is not available with either the PM240‑2 power module or the
PM240P‑2 power module.
The compound braking is not available with either the PM230 power module or the PM330
power module.
Electrically braking the motor (Page 311)
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 5
