10.3.5 Detailed technical data, PM230
Table 10-9 PM230, IP20, frame size A, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1NE11-3UG1
6SL3210-1NE11-3AG1
6SL3210-1NE11-7UG1
6SL3210-1NE11-7AG1
6SL3210-1NE12-2UG1
6SL3210-1NE12-2AG1
LO base load power 0.37 kW 0.55 kW 0.75 kW
LO base load input current 1.3 A 1.8 A 2.3 A
LO base load output current 1.3 A 1.7 A 2.2 A
HO base load power 0.25 kW 0.37 kW 0.55 kW
HO base load input current 0.9 A 1.3 A 1.8 A
HO base load output current 0.9 A 1.3 A 1.7 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
2 A
3NE1813-0
4 A
3NE1813-0
4 A
Circuit breaker 3RV2711-1KD10 12.5 A 12.5 A 12.5 A
Power loss 0.04 kW 0.04 kW 0.05 kW
Required cooling air flow 1.5 l/s 1.5 l/s 4.5 l/s
Weight without filter 1.4 kg 1.4 kg 1.4 kg
Weight with filter 1.6 kg 1.6 kg 1.6 kg
Table 10-10 PM230, IP20, frame size A, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1NE13-1UG1
6SL3210-1NE13-1AG1
6SL3210-1NE14-1UG1
6SL3210-1NE14-1AG1
6SL3210-1NE15-8UG1
6SL3210-1NE15-8AG1
LO base load power 1.1 kW 1.5 kW 2.2 kW
LO base load input current 3.2 A 4.2 A 6.1 A
LO base load output current 3.1 A 4.1 A 5.9 A
HO base load power 0.75 kW 1.1 kW 1.5 kW
HO base load input current 2.3 A 3.2 A 4.2 A
HO base load output current 2.2 A 3.1 A 4.1 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
6 A
3NE1813-0
6 A
3NE1813-0
10 A
Power loss 0.06 kW 0.07 kW 0.08 kW
Circuit breaker N3RV2711-1KD10 12.5 A 12.5 A 12.5 A
Required cooling air flow 4.5 l/s 4.5 l/s 4.5 l/s
Weight without filter 1.4 kg 1.4 kg 1.4 kg
Weight with filter 1.6 kg 1.6 kg 1.6 kg
Table 10-11 PM230, IP20, frame size A, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1NE17-7UG1
6SL3210-1NE17-7AG1
LO base load power 3 kW
LO base load input current 8.0 A
Technical data
10.3 Technical data, PM230 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 447
