Siemens CU240B-2 Operating Instructions

Article number without filter
Article number with filter
6SL3210-1NE17-7UG1
6SL3210-1NE17-7AG1
LO base load output current 7.7 A
HO base load power 2.2 kW
HO base load input current 6.1 A
HO base load output current 5.9 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
10 A
Circuit breaker N3RV2711-1KD10 12.5 A
Power loss 0.11 kW
Required cooling air flow 4.5 l/s
Weight without filter 1.4 kg
Weight with filter 1.6 kg
Table 10-12 PM230, PT, frame size A, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3211-1NE17-7UG1
6SL3211-1NE17-7AG1
LO base load power 3 kW
LO base load input current 8.0 A
LO base load output current 7.7 A
HO base load power 2.2 kW
HO base load input current 6.1 A
HO base load output current 5.9 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
10 A
Power loss 0.11 kW
Required cooling air flow 4.5 l/s
Weight without filter 1.7 kg
Weight with filter 1.9 kg
Table 10-13 PM230, IP20, frame size B, 3-phase 380 … 480 VAC
Article number without filter
Article number with filter
6SL3210-1NE21-0UG1
6SL3210-1NE21-0AG1
6SL3210-1NE21-3UG1
6SL3210-1NE21-3AG1
6SL3210-1NE21-8UG1
6SL3210-1NE21-8AG1
LO base load power 4 kW 5.5 kW 7.5 kW
LO base load input current 10.5 A 13.6 A 18.6 A
LO base load output current 10.2 A 13.2 A 18 A
HO base load power 3 kW 4 kW 5.5 kW
HO base load input current 8.0 A 10.5 A 13.6 A
HO base load output current 7.7 A 10.2 A 13.2 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1813-0
15 A
3NE1814-0
20 A
3NE1815-0
25 A
Technical data
10.3 Technical data, PM230 Power Module
Converter with the CU230P-2 Control Units
448 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
