Siemens CU240B-2 Operating Instructions

10.6.3 Specific technical data, 200 V inverters
Table 10-36 PM240-2, IP20, frame size A, 200 V … 240 V 1 AC / 3 AC
Article No. without filter
Article No. with filter
6SL3210-1PB13-0UL0
6SL3210-1PB13-0AL0
6SL3210-1PB13-8UL0
6SL3210-1PB13-8AL0
LO base load power 0.55 kW 0.75 kW
1 AC LO base load input current 7.5 A 9.6 A
3 AC LO base load input current 4.2 A 5.5 A
LO base load output current 3.2 A 4.2 A
HO base load power 0.37 kW 0.55 kW
1 AC HO base load input current 6.6 A 8.4 A
3 AC HO base load input current 3.0 A 4.2 A
HO base load output current 2.3 A 3.2 A
Fuse according to IEC
Fuse according to UL, class J
3NA3805 (16 A)
15 A
3NA3805 (16 A)
15 A
Power loss 0.04 kW 0.04 kW
Required cooling air flow 5 l/s 5 l/s
Weight without filter 1.4 kg 1.4 kg
Weight with filter 1.6 kg 1.6 kg
Table 10-37 PM240-2, PT, frame size A, 200 V … 240 V 1 AC / 3 AC
Article No. without filter
Article No. with filter
6SL3211-1PB13-8UL0
6SL3211-1PB13-8AL0
LO base load power 0.75 kW
1 AC LO base load input current 9.6 A
3 AC LO base load input current 5.5 A
LO base load output current 4.2 A
HO base load power 0.55 kW
1 AC HO base load input current 8.4 A
3 AC HO base load input current 4.2 A
HO base load output current 3.2 A
Fuse according to IEC
Fuse according to UL, class J
3NA3 805 (16 A)
15 A
Power loss 0.04 kW
Required cooling air flow 5 l/s
Weight without filter 1.8 kg
Weight with filter 2.0 kg
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 479
