Table 10-38 PM240-2, IP20, frame size B, 200 V … 240 V 1 AC / 3 AC
Article No. without filter
Article No. with filter
6SL3210-1PB15-5UL0
6SL3210-1PB15-5AL0
6SL3210-1PB17-4UL0
6SL3210-1PB17-4AL0
6SL3210-1PB21-0UL0
6SL3210-1PB21-0AL0
LO base load power 1.1 kW 1.5 kW 2.2 kW
1 AC LO base load input current 13.5 A 18.1 A 24.0 A
3 AC LO base load input current 7.8 A 9.7 A 13.6 A
LO base load output current 6 A 7.4 A 10.4 A
HO base load power 0.75 kW 1.1 kW 1.5 kW
1 AC HO base load input current 11.8 A 15.8 A 20.9 A
3 AC HO base load input current 5.5 A 7.8 A 9.7 A
HO base load output current 4.2 A 6 A 7.4 A
Fuse according to IEC
Fuse according to UL, class J
3NA3812 (32 A)
35 A
3NA3812 (32 A)
35 A
3NA3812 (32 A)
35 A
Power loss 0.05 kW 0.07 kW 0.12 kW
Required cooling air flow 9.2 l/s 9.2 l/s 9.2 l/s
Weight without filter 2.8 kg 2.8 kg 2.8 kg
Weight with filter 3.1 kg 3.1 kg 3.1 kg
Table 10-39 PM240-2, PT, frame size B, 200 V … 240 V 1 AC / 3 AC
Article No. without filter
Article No. with filter
6SL3211-1PB21-0UL0
6SL3211-1PB21-0AL0
LO base load power 2.2 kW
1 AC LO base load input current 24.0 A
3 AC LO base load input current 13.6 A
LO base load output current 10.4 A
HO base load power 1.5 kW
1 AC HO base load input current 20.9 A
3 AC HO base load input current 9.7 A
HO base load output current 7.4 A
Fuse according to IEC
Fuse according to UL, class J
3NA3812 (32 A)
35 A
Power loss 0.12 kW
1)
Required cooling air flow 9.2 l/s
Weight without filter 3.4 kg
Weight with filter 3.7 kg
1)
approx. 0.08 kW through the heat sink
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
480 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
