10.3.3 Specific technical specifications PM230, IP55
Table 10-1 PM230, IP55, Frame Size A, 3-ph. AC 380 V … 480 V
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE13-7AG1
6SL3223-0DE13-7BG1
6SL3223-0DE15-5AG
6SL3223-0DE15-5BG1
6SL3223-0DE17-5AG1
6SL3223-0DE17-5BG1
LO base load power 0.37 kW 0.55 kW 0.75 kW
LO base load input current 1.3 A 1.8 A 2.3 A
LO base load output current 1.3 A 1.7 A 2.2 A
HO base load power 0.25 kW 0.37 kW 0.55 kW
HO base load input current 0.9 A 1.3 A 1.8 A
HO base load output current 0.9 A 1.3 A 1.7 A
Fuse according to IEC
Fuse according to UL, class J
3NA3803
10 A
3NA3803
10 A
3NA3803
10 A
Power loss 0.06 kW 0.06 kW 0.06 kW
Required cooling air flow 7 l/s 7 l/s 7 l/s
Weight 4.3 kg 4.3 kg 4.3 kg
Table 10-2 PM230, IP55, Frame Size A, 3-ph. AC 380 V … 480 V
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE21-1AG1
6SL3223-0DE21-1BG1
6SL3223-0DE21-5AG1
6SL3223-0DE21-5BG1
6SL3223-0DE22-2AG1
6SL3223-0DE22-2BG1
LO base load power 1.1 kW 1.5 kW 2.2 kW
LO base load input current 3.2 A 4.2 A 6.1 A
LO base load output current 3.1 A 4.1 A 5.9 A
HO base load power 0.75 kW 1.1 kW 1.5 kW
HO base load input current 2.3 A 3.2 A 4.2 A
HO base load output current 2.2 A 3.1 A 4.1 A
Fuse according to IEC
Fuse according to UL, class J
3NA3803
10 A
3NA3803
10 A
3NA3803
10 A
Power loss 0.07 kW 0.08 kW 0.1 kW
Required cooling air flow 7 l/s 7 l/s 7 l/s
Weight 4.3 kg 4.3 kg 4.3 kg
Table 10-3 PM230, IP55, Frame Size A, 3-ph. AC 380 V … 480 V
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE23-0AG1
6SL3223-0DE23-0BG1
LO base load power 3 kW
LO base load input current 8.0 A
LO base load output current 7.7 A
HO base load power 2.2 kW
HO base load input current 6.1 A
HO base load output current 5.9 A
Technical data
10.3 Technical data, PM230 Power Module
Converter with the CU230P-2 Control Units
442 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
