8.3 Identification & maintenance data (I&M)
I&M data
The inverter supports the following identification and maintenance (I&M) data.
I&M
data
Format Explanation Associated pa‐
rameters
Example for the
content
I&M0 u8[64] PROFIBUS
u8[54] PROFINET
Inverter-specific data, read only - See below
I&M1 Visible String [32] Plant/system identifier p8806[0 … 31] "ak12-
ne.bo2=fu1"
Visible String [22] Location code p8806[32 … 53] "sc2+or45"
I&M2 Visible String [16] Date p8807[0 … 15] "2013-01-21
16:15"
I&M3 Visible String [54] Any comment p8808[0 … 53] -
I&M4 Octet String[54] Check signature to track changes
for Safety Integrated.
This value can be changed by the
user.
The test signature is reset to the
value generated by the machine
is p8805 = 0 is used.
p8809[0 … 53] Values of
r9781[0] and
r9782[0]
When requested, the inverted transfers its I&M data to a higher-level control or to a PC/PG
with installed STEP 7, STARTER or TIA-Portal.
I&M0
Designation Format Example for the
content
Valid for PRO‐
FINET
Valid for PRO‐
FIBUS
Manufacturer-specific u8[10] 00 … 00 hex --- ✓
MANUFACTURER_ID u16 42d hex (=Sie‐
mens)
✓ ✓
ORDER_ID Visible String
[20]
„6SL3246-0BA22-
1FA0“
✓ ✓
SERIAL_NUMBER Visible String
[16]
„T-R32015957“ ✓ ✓
HARDWARE_REVISION u16 0001 hex ✓ ✓
SOFTWARE_REVISION char, u8[3] „V“ 04.70.19 ✓ ✓
REVISION_COUNTER u16 0000 hex ✓ ✓
PROFILE_ID u16 3A00 hex ✓ ✓
PROFILE_SPECIFIC_TYPE u16 0000 hex ✓ ✓
IM_VERSION u8[2] 01.02 ✓ ✓
IM_SUPPORTED bit[16] 001E hex ✓ ✓
Alarms, faults and system messages
8.3 Identification & maintenance data (I&M)
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 399
