10.9.2 PM240-2 and PM240P-2 Power Modules: Current reduction as a function of the
installation altitude and ambient temperature
Current reduction as a function of the installation altitude and ambient temperature
At installation altitudes above 1000 m and temperatures higher than 40° C (low overload) or
50° C (high overload), the inverter output current is reduced. The following tables contain the
details.
Table 10-78 Maximum permitted output current for loading according to LO
Installation
altitude [m]
up to
Ambient temperature [°C]
20 25 30 35 40 45 50 55 60
Output current in [%] when loading to LO
1000 100 93 85 76 66
1500 100 95 88 81 72 63
2000 100 97 90 83 77 68 59
2500 100 98 91 85 79 72 64 56
3000 100 98 92 86 80 74 68 60 53
3500 98 92 86 81 75 69 64 57 50
4000 91 86 81 75 70 65 60 53 46
Table 10-79 Maximum permitted output current when loading according to HO
Installation
altitude [m]
up to
Ambient temperature [°C]
20 25 30 35 40 45 50 55 60
Output current in [%] when loading to HO
1000 100 87 74
1500 100 95 83 70
2000 100 99 95 90 78 67
2500 100 98 94 89 85 74 63
3000 100 96 92 88 84 80 70 59
3500 98 94 90 86 83 79 75 65 56
4000 91 88 84 81 77 74 70 61 52
Also observe the maximum permissible ambient operating temperatures for the Control Unit
and possibly the Operator Panel.
