10.4.4 Current derating depending on the pulse frequency, 400 V inverters
Article number LO
power
[kW]
LO base load output current [A]
Pulse frequency [kHz] 2 4
*)
6 8 10 12 14 16
6SL3210-1RE24-5 . L0 22 45 45 38.3 31.5 27 22.5 20.3 18
6SL3210-1RE26-0 . L0 30 60 60 51 42 36 30 27 24
6SL3210-1RE27-5 . L0 37 75 75 63.8 52.5 45 37.5 33.8 30
6SL3210-1RE28-8 . L0 45 90 90 76.5 63 54 45 40.5 36
6SL3210-1RE31-1 . L0 55 110 110 93.5 77 --- --- --- ---
Pulse frequency [kHz] 2
*)
4 6 8 10 12 14 16
6SL3210-1RE31-5 . L0 75 145 145 123.3 101.5 --- --- --- ---
6SL3210-1RE31-8 . L0 90 178 178 151.3 124.6 --- --- --- ---
6SL3210-1RE32-1 . L0 110 205 143.5 --- --- --- --- --- ---
6SL3210-1RE32-5 . L0 132 250 175 --- --- --- --- --- ---
*) Factory setting
The permissible motor cable length depends on the particular cable type and the pulse frequency that
has been selected
Technical data
10.4 Technical Data, PM240P-2 Power Module
Converter with the CU230P-2 Control Units
458 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
