Siemens CU240B-2 Operating Instructions

Appendix
A
A.1 New and extended functions
A.1.1 Firmware version 4.7 SP9
Table A-1 New functions and function changes in firmware 4.7 SP9
Function SINAMICS
G120 G120D
*0
*&
&83
&8%
&8(
&86
&8'
&8'
(7SUR)&
1 Support of PM240‑2 FSG Power Modules - - ✓ ✓ ✓ ✓ - - -
2 Support of PM240‑2 Power Modules in push-through technology, frame
sizes FSD … FSF, for the following voltages:
● 3 AC 200 V … 240 V
● 3 AC 380 V … 480 V
● 3 AC 500 V … 690 V
- - ✓ ✓ ✓ ✓ - - -
3 Support of PM240‑2 Power Modules, 3 AC 500 V … 690 V, frame size FSD
with reduced power 3 kW … 7.5 kW
- - ✓ ✓ ✓ ✓ - - -
4 Shortened switch-on time for PM330 Power Modules - - ✓ - - - - - -
5 Expansion of the support for 1FP1 synchronous-reluctance motor with the
following inverters:
● SINAMICS G110M
● SINAMICS G120D
● SINAMICS G120 with CU240B‑2 or CU240E‑2 Control Unit
A PM240‑2 Power Module is required to operate a 1FP1 synchronous-re‐
luctance motor with SINAMICS G120
✓ - ✓ ✓ ✓ - ✓ - -
6 Support of 1FP3 synchronous-reluctance motors
A PM240‑2 Power Module is required to operate a 1FP3 synchronous-re‐
luctance motor along with a selective release from SIEMENS
- - ✓ - - - - - -
7 Support of 1LE5 induction motors - ✓ ✓ ✓ ✓ ✓ - - -
8 The inverter supports forming the PM330 Power Module DC link capacitors - - ✓ - - - - - -
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 515
