10.6.9 Specific technical data, 690 V inverters
Table 10-65 PM240-2, IP20, frame size D, 500 V … 690 V 3 AC
Article No. - without filter
Article No. - with filter
6SL3210-1PH21-4UL0
6SL3210-1PH21-4AL0
6SL3210-1PH22-0UL0
6SL3210-1PH22 -0AL0
6SL3210-1PH22-3UL0
6SL3210-1PH22 -3AL0
LO base load power 11 kW 15 kW 18.5 kW
LO base load input current 14 A 18 A 22 A
LO base load output current 14 A 19 A 23 A
HO base load power 7.5 kW 11 kW 15 kW
HO base load input current 11 A 14 A 20 A
HO base load output current 11 A 14 A 19 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3807-6 (20 A)
20 A
3NA3810-6 (25 A)
25 A
3NA3812-6 (32 A)
30 A
Power loss without filter 0.35 kW 0.44 kW 0.52 kW
Power loss with filter 0.35 kW 0.45 kW 0.52 kW
Required cooling air flow 55 l/s 55 l/s 55 l/s
Weight without filter 17 kg 17 kg 17 kg
Weight with filter 18.5 kg 18.5 kg 18.5 kg
Table 10-66 PM240-2, IP20, frame size D, 500 V … 690 V 3 AC
Article No. - without filter
Article No. - with filter
6SL3210-1PH22-7UL0
6SL3210-1PH22-7AL0
6SL3210-1PH23-5UL0
6SL3210-1PH23 -5AL0
6SL3210-1PH24-2UL0
6SL3210-1PH24-2AL0
LO base load power 22 kW 30 kW 37 kW
LO base load input current 25 A 33 A 40 A
LO base load output current 27 A 35 A 42 A
HO base load power 18.5 kW 22 kW 30 kW
HO base load input current 24 A 28 A 36 A
HO base load output current 23 A 27 A 35 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3817-6KJ (40 A)
35 A
3NA3820-6KJ (50 A)
45 A
33NA3822-6 (63 A)
60 A
Power loss without filter 0.60 kW 0.77 kW 0.93 kW
Power loss with filter 0.60 kW 0.78 kW 0.94 kW
Required cooling air flow 55 l/s 55 l/s 55 l/s
Weight without filter 17 kg 17 kg 17 kg
Weight with filter 18.5 kg 18.5 kg 18.5 kg
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
498 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
