3.5.6 dv/dt filter
du/dt filters for the PM330 Power Module, 380 V … 480 V
A du/dt filter plus VPL (Voltage Peak Limiter) limits the voltage rate of rise du/dt and the voltage
peaks at the motor. A du/dt filter plus VPL allows standard motors with standard insulation and
without insulated bearings to be operated at the inverter.
Power Module Power du/dt filter plus VPL du/dt filter compact plus
VPL
GX 6SL3310-1PE33-0AA0,
6SL3310-1PE33-7AA0,
6SL3310-1PE34-6AA0
160 kW …
250 kW
6SL3000-2DE35-0AA0 6SL3000-2DE35-0EA0
HX 6SL3310-1PE35-8AA0,
6SL3310-1PE36-6AA0,
6SL3310-1PE37-4AA0
315 kW …
400 kW
6SL3000-2DE38-4AA0 6SL3000-2DE38-4EA0
JX 6SL3310-1PE38-4AA0,
6SL3310-1PE38-8AA0,
6SL3310-1PE41-0AA0
450 kW …
560 kW
6SL3000-2DE41-4AA0 6SL3000-2DE41-4EA0
du/dt filters for the PM330 Power Module, 500 V … 690 V
Power Module Power du/dt filter plus VPL du/dt filter compact plus
VPL
JX 6SL3310-1PG35-8AA0,
6SL3310-1PG36-5AA0,
6SL3310-1PG37-2AA0
500 kW …
630 kW
6SL3000-2DH38-1AA0 6SL3000-2DG38-1EA0
Description
3.5 Components for the Power Modules
Converter with the CU230P-2 Control Units
52 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
