● ROT: Measure the motor data while it is rotating.
The inverter switches off the motor after the motor data identification has been completed.
● ST RT OP: setting same as STIL ROT.
The motor accelerates to the currently set setpoint after the motor data identification.
● STILL OP: setting same as STILL.
The motor accelerates to the currently set setpoint after the motor data identification.
Complete the basic commissioning:
Switch over the display using an arrow key: nO → YES
Press the OK key.
You have entered all of the data that is necessary for the basic commissioning of your inverter.
5.4.3.4 Expert
Select the motor standard:
● KW / 50HZ: IEC
● HP / 60HZ: NEMA
● KW / 60HZ: IEC 60 Hz
Specify the overload capability of the inverter:
● HIGH OVL: Load cycle with "High Overload"
● LOW OVL: Load cycle with "Low Overload"
AUTOHOTSPOT
Set the supply voltage of the inverter.
Select the motor type. If a 5-digit motor code is stamped on the motor rating plate, select the
corresponding motor type with motor code.
Motors without motor code stamped on the rating plate:
● INDUCT: Third-party induction motor
● 1L… IND: 1LE1, 1LG6, 1LA7, 1LA9 induction motors
Motors with motor code stamped on the rating plate:
● 1LE1 IND 100: 1LE1 . 9
● 1PC1 IND: 1PC1
● 1PH8 IND: Induction motor
● 1FP1: Reluctance motor
Depending on the inverter, the motor list in BOP-2 can deviate from the list shown above.
If you have selected a motor type with motor code, you must now enter the motor code. The
inverter assigns the following motor data corresponding to the motor code.
If you do not know the motor code, then you must set the motor code = 0, and enter motor
data from p0304 and higher from the rating plate.
Commissioning
5.4 Quick commissioning using the BOP-2 operator panel
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 167
