2.2 Guide through the manual
Section In this section you will find answers to the following questions:
Description (Page 29)
● How is the inverter marked?
● Which components make up the inverter?
● Which optional components are available for the inverter?
● What is the purpose of the optional components?
● Which motors can be fed from the inverter?
● Which commissioning tools are there?
Installing (Page 57)
● Which sequence is recommended when installing the inverter?
● What does EMC-compliant installation actually mean?
● Which options are available to install optional components below the inverter?
● What are the inverter dimensions?
● Which mounting and installation materials are required when installing the inverter?
● To which line supplies can the inverter be connected?
● How is the inverter connected to the line supply?
● How is the braking resistor connected to the inverter?
● Which terminals and fieldbus interfaces does the inverter have?
● What are the interface functions?
Commissioning (Page 145)
● Which motor data is required for commissioning
● How is the inverter set in the factory?
● What is the commissioning procedure?
● How do you restore the inverter factory settings?
Advanced commissioning
(Page 191)
● Which functions are included in the inverter firmware?
● How do the functions interoperate with one another?
● How are the functions set?
Saving the settings and ser‐
ies commissioning (Page 369)
● Why is it necessary to back up the inverter settings?
● Which options are available to back up the settings?
● How does the data backup function?
● How do you prevent the inverter settings from being changed?
● How do you prevent the inverter settings from being read out?
Corrective maintenance
(Page 415)
● How are inverter components replaced?
● How do you change the firmware version of the inverter?
Alarms, faults and system
messages (Page 395)
● What is the meaning of the LEDs provided on the inverter?
● How does the system runtime respond?
● How does the inverter save alarms and faults?
● What do the inverter alarms and faults mean?
● How are inverter faults resolved?
● Which I&M data is saved in the inverter?
Introduction
2.2 Guide through the manual
Converter with the CU230P-2 Control Units
26 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
