10.6.7 Current derating depending on the pulse frequency, 400 V inverters
Article number LO
power
[kW]
LO base load output current [A]
Pulse frequency [kHz] 2 4
*)
6 8 10 12 14 16
6SL3210-1PE11-8 . L1 0.55 1.7 1.7 1.4 1.2 1 0.9 0.8 0.7
6SL3210-1PE12-3 . L1 0.75 2.2 2.2 1.9 1.5 1.3 1.1 1 0.9
6SL3211-1PE13-2 . L1 1.1 3.1 3.1 2.6 2.2 1.9 1.6 1.4 1.2
6SL3210-1PE14-3 . L1 1.5 4.1 4.1 3.5 2.9 2.5 2.1 1.8 1.6
6SL3210-1PE16-1 . L1 2.2 5.9 5.9 5 4.1 3.5 3 2.7 2.4
6SL321 . -1PE18-0 . L1 3 7.7 7.7 6.5 5.4 4.6 3.9 3.5 3.1
6SL3210-1PE21-1 . L0 4 10.2 10.2 8.7 7.1 6.1 5.1 4.6 4.1
6SL3210-1PE21-4 . L0 5.5 13.2 13.2 11.2 9.2 7.9 6.6 5.9 5.3
6SL321 . -1PE21-8 . L0 7.5 18 18 15.3 12.6 10.8 9 8.1 7.2
6SL3210-1PE22-7 . L0 11 26 26 22.1 18.2 15.6 13 11.7 10.4
6SL321 . -1PE23-3 . L0 15 32 32 27.2 22.4 19.2 16 14.4 12.8
6SL3210-1PE23-8 . L0 18.5 38 38 32.3 26.6 22.8 19 17.1 15.2
6SL3210-1PE24-5 . L0 22 45 45 38.3 31.5 27 22.5 20.3 18
6SL3210-1PE26-0 . L0 30 60 60 51 42 36 30 27 24
6SL321 . -1PE27-5 . L0 37 75 75 63.8 52.5 45 37.5 33.8 30
6SL3210-1PE28-8 . L0 45 90 90 76.5 63 54 45 40.5 36
6SL321 . -1PE31-1 . L0 55 110 110 93.5 77 --- --- --- ---
Pulse frequency [kHz] 2
*)
4 6 8 10 12 14 16
6SL3210-1PE31-5 . L0 75 145 145 123.3 101.5 --- --- --- ---
6SL3210-1PE31-8 . L0 90 178 178 151.3 124.6 --- --- --- ---
6SL3210-1PE32-1 . L0 110 205 143.5 --- --- --- --- --- ---
6SL321 . -1PE32-5 . L0 132 250 175 --- --- --- --- --- ---
*) Factory setting
The permissible motor cable length depends on the particular cable type and the pulse frequency that
has been selected
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
496 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
