Table 10-64 PM240-2, PT, frame size F, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3211-1PE31-1UL0
6SL3211-1PE31-1AL0
LO base load power 132 kW
LO base load input current 242 A
LO base load output current 250 A
HO base load power 110 kW
HO base load input current 218 A
HO base load output current 205 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3252 (315 A)
350 A
Power loss without filter 2.98 kW
1)
Power loss with filter 3.02 kW
1)
Required cooling air flow 153 l/s
Weight without filter 63.5 kg
Weight with filter 68 kg
1)
Approx. 2.6 kW through the heatsink
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 495
