3.5.2 Line filter
With a line filter, the inverter can achieve a higher radio interference class.
NOTICE
Overloading the line filter when connected to line supplies that are not permissible
The line filter is only suitable for operation on TN or TT line supplies with a grounded neutral
point. If operated on other line supplies, the line filter will be thermally overloaded and will be
damaged.
● For inverters equipped with line filter, only connect to TN or TT line supplies with a
grounded neutral point.
External line filters for PM230, 380 V … 480 V (IP20)
Power Module Power Line filter according to
EN 61800‑3 Category C1
FSA 6SL3210‑1NE11‑3UG1,
6SL3210‑1NE11‑7UG1,
6SL3210‑1NE12‑2UG1,
6SL3210‑1NE13‑1UG1,
6SL3210‑1NE14‑1UG1,
6SL3210‑1NE15‑8UG1,
6SL321 . ‑1NE17‑7UG1 .
0.37 kW … 3 kW 6SL3203‑0BE17‑7BA0
FSB 6SL3210‑1NE21‑0UG1,
6SL3210‑1NE21‑3UG1,
6SL321 . ‑1NE21‑8UG1
4 kW … 7.5 kW 6SL3203‑0BE21‑8BA0
FSC 6SL3210‑1NE22‑6UG1,
6SL3210‑1NE23‑2UG1,
6SL321 . ‑1NE23‑8UG1
11 kW … 18.5 kW 6SL3203‑0BE23‑8BA0
FSD 6SL3210‑1NE24‑5UL0,
6SL3210‑1NE26‑0UL0
22 kW … 30 kW 6SL3203‑0BE27‑5BA0
FSE 6SL3210‑ 1NE27‑5UL0,
6SL3210‑ 1NE28‑8UL0
37 kW … 45 kW 6SL3203‑0BE31‑1BA0
FSF 6SL3210‑1NE31‑1UL0,
6SL3210‑1NE31‑5UL0
55 kW … 75 kW 6SL3203‑0BE31‑8BA0
External line filters for PM330, 380 V … 480 V
Power Module Power Line filter according to
EN 61800‑3 Category C2
GX 6SL3310-1PE33‑0AA0,
6SL3310-1PE33‑7AA0
160 kW … 200 kW 6SL3000-0BE33-1AA0
6SL3310-1PE34-6AA0 250 kW 6SL3000-0BE35-0AA0
Description
3.5 Components for the Power Modules
Converter with the CU230P-2 Control Units
42 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
