10.7.3 Specific technical data, PM250
Note
The values for Low Overload (LO) are identical with those of the rated values.
Table 10-73 PM250, IP20, Frame Size C, 3-ph. AC 380 V … 480 V
Article no. 6SL3225-0BE25-5AA1 6SL3225-0BE27-5AA1 6SL3225-0BE31-1AA1
LO base load output 7.5 kW 11 kW 15 kW
LO base load input current 18 A 25 A 32 A
LO base load output current 18 A 25 A 32 A
HO base load output 5.5 kW 7.5 kW 11 kW
HO base load input current 13.2 A 19 A 26 A
HO base load output current 13.2 A 19 A 26 A
Fuse 20 A, Class J 32 A, Class J 35 A, Class J
Power loss 0.24 kW 0.30 kW 0.31 kW
Required cooling air flow 38 l/s 38 l/s 38 l/s
Weight 7.5 kg 7.5 kg 7.5 kg
Table 10-74 PM250, IP20, Frame Size D, 3-ph. AC 380 V … 480 V
Article no. 6SL3225-0BE31-5AA0 6SL3225-0BE31-8AA0 6SL3225-0BE32-2AA0
LO base load output 18.5 kW 22 kW 30 kW
LO base load input current 36 A 42 A 56 A
LO base load output current 38 A 45 A 60 A
HO base load output 15 kW 18.5 kW 22 kW
HO base load input current 30 A 36 A 42 A
HO base load output current 32 A 38 A 45 A
Fuse according to IEC
Fuse according to UL
3NA3820
50 A, Class J
3NE1817-0
3NA3822
63 A, Class J
3NE1818-0
3NA3824
80 A, Class J
3NE1820-0
Power loss 0.44 kW 0.55 kW 0.72 kW
Required cooling air flow 22 l/s 22 l/s 39 l/s
Weight 15 kg 15 kg 16 kg
Table 10-75 PM250, IP20, Frame Size E, 3-ph. AC 380 V … 480 V
Article no. 6SL3225-0BE33-0AA0 6SL3225-0BE33-7AA0
LO base load output 37 kW 45 kW
LO base load input current 70 A 84 A
LO base load output current 75 A 90 A
Technical data
10.7 Technical data, PM250 Power Module
Converter with the CU230P-2 Control Units
506 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
