3.4.1 Power module for the SINAMICS G120P
30,3
)6$)6&
30,3
)6')6)
Figure 3-1 PM230, 3-phase 400 VAC, degree of protection IP55 / UL Type 12
PM230 for pumps and fan applications
The PM230 Power Module is suitable for cabinet-free installation.
Table 3-2 3-phase 380 VAC … 480 VAC, article number 6SL3223-0DE…
Frame size FSA FSB FSC FSD FSE FSF
Power (kW) Filter Class A 0.37 … 3 4 … 7.5 11 … 18.5 22 … 30 37 … 45 55 … 90
Filter Class B 0.37 … 3 4 … 7.5 11 … 15 18.5 … 30 37 … 45 55 … 90
Description
3.4 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 35
