Power Module Power Line filter according to
EN 61800‑3 Category C2
HX 6SL3310-1PE35-8AA0,
6SL3310-1PE36-6AA0,
6SL3310-1PE37-4AA0
315 kW … 400 kW 6SL3760-0MR00-0AA0
JX 6SL3310-1PE38-4AA0,
6SL3310-1PE38-8AA0,
6SL3310-1PE41-0AA0
450 kW … 560 kW
External line filters for the PM330 Power Module, 500 V … 690 V
Power Module Power Line filter according to
EN 61800‑3 Category C2
HX 6SL3310‑1PG33‑7AA0,
6SL3310‑1PG34‑0AA0,
6SL3310‑1PG34‑5AA0,
6SL3310-1PG35-2AA0
315 kW … 450 kW 6SL3760-0MS00-0AA0
JX 6SL3310-1PG35-8AA0,
6SL3310-1PG36-5AA0,
6SL3310-1PG37-2AA0
500 kW … 630 kW 6SL3760-0MS00-0AA0
External line filters for PM250
Power Module Power Class B line filter according to
EN55011: 2009
FSC 6SL3225-0BE25‑5AA0,
6SL3225-0BE27‑5AA0,
6SL3225-0BE31‑1AA0
7.5 kW … 15.0 kW 6SL3203-0BD23-8SA0
Description
3.5 Components for the Power Modules
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 43
