Table 10-22 PM240P-2, IP20, Frame Size F, 3-ph. AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1RE31-5UL0
6SL3210-1RE31-5AL0
6SL3210-1RE31-8UL0
6SL3210-1RE31-8AL0
6SL3210-1RE32-1UL0
6SL3210-1RE32-1AL0
LO base load power 75 kW 90 kW 110 kW
LO base load input current 140 A 172 A 198 A
LO base load output current 145 A 178 A 205 A
HO base load power 55 kW 75 kW 90 kW
HO base load input current 117 A 154 A 189 A
HO base load output current 110 A 145 A 178 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1225-0 / 200 A
200 A
3NE1227-0 / 250 A
250 A
3NE1230-0 / 315 A
300 A
Power loss without filter 1.95 kW 2.54 kW 2.36 kW
Power loss with filter 1.97 kW 2.56 kW 2.38 kW
Required cooling air flow 153 l/s 153 l/s 153 l/s
Weight without filter 57 kg 57 kg 61 kg
Weight with filter 63 kg 63 kg 65 kg
Table 10-23 PM240P-2, IP20, Frame Size F, 3-ph. AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1RE32-5UL0
6SL3210-1RE32-5AL0
LO base load power 132 kW
LO base load input current 242 A
LO base load output current 250 A
HO base load power 110 kW
HO base load input current 218 A
HO base load output current 205 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1331-0 / 350 A
350 A
Power loss without filter 3.09 kW
Power loss with filter 3.12 kW
Required cooling air flow 153 l/s
Weight without filter 61 kg
Weight with filter 65 kg
Technical data
10.4 Technical Data, PM240P-2 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 457
