Siemens CU240B-2 Operating Instructions

Table 10-40 PM240-2, IP 20, frame size C, 200 V … 240 V 1 AC / 3 AC
Article No. without filter
Article No. with filter
6SL3210-1PB21-4UL0
6SL3210-1PB21-4AL0
6SL3210-1PB21-8UL0
6SL3210-1PB21-8AL0
LO base load power 3 kW 4 kW
1 AC LO base load input current 35.9 A 43.0 A
3 AC LO base load input current 17.7 A 22.8 A
LO base load output current 13.6 A 17.5 A
HO base load power 2.2 kW 3 kW
1 AC HO base load input current 31.3 A 37.5 A
3 AC HO base load input current 13.6 A 17.7 A
HO base load output current 10.4 A 13.6 A
Fuse according to IEC
Fuse according to UL, class J
3NA3820 (50 A)
50 A
3NA3820 (50 A)
50 A
Power loss 0.14 kW 0.18 kW
Required cooling air flow 18.5 l/s 18.5 l/s
Weight without filter 5.0 kg 5.0 kg
Weight with filter 5.2 kg 5.2 kg
Table 10-41 PM240-2, PT, frame size C, 200 V … 240 V 1 AC / 3 AC
Article No. without filter
Article No. with filter
6SL3211-1PB21-8UL0
6SL3211-1PB21-8AL0
LO base load power 4 kW
1 AC LO base load input current 43.0 A
3 AC LO base load input current 22.8 A
LO base load output current 17.5 A
HO base load power 3 kW
1 AC HO base load input current 37.5 A
3 AC HO base load input current 17.7 A
HO base load output current 13.6 A
Fuse according to IEC
Fuse according to UL, class J
3NA3820 (50 A)
50 A
Power loss 0.18 kW
1)
Required cooling air flow 18.5 l/s
Weight without filter 5.9 kg
Weight with filter 6.2 kg
1)
approx. 0.09 kW through the heat sink
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 481
