Table 10-42 PM240-2, IP 20, frame size C, 200 V … 240 V 3 AC
Article No. without filter
Article No. with filter
6SL3210-1PC22-2UL0
6SL3210-1PC22-2AL0
6SL3210-1PC22-8UL0
6SL3210-1PC22-8AL0
LO base load power 5.5 kW 7.5 kW
LO base load input current 28.6 A 36.4 A
LO base load output current 22.0 A 28.0 A
HO base load power 4 kW 5.5 kW
HO base load input current 22.8 A 28.6 A
HO base load output current 17.5 A 22.0 A
Fuse according to IEC
Fuse according to UL, class J
3NA3820 (50 A)
50 A
3NA3820 (50 A)
50 A
Power loss 0.2 kW 0.26 kW
Required cooling air flow 18.5 l/s 18.5 l/s
Weight without filter 5.0 kg 5.0 kg
Weight with filter 5.2 kg 5.2 kg
Table 10-43 PM240-2, PT, frame size C, 200 V … 240 V 3 AC
Article No. without filter
Article No. with filter
6SL3211-1PC22-2UL0
6SL3211-1PC22-2AL0
6SL3211-1PC22-8UL0
6SL3211-1PC22-8AL0
LO base load power 5.5 kW 7.5 kW
LO base load input current 28.6 A 36.4 A
LO base load output current 22.0 A 28.0 A
HO base load power 4 kW 5.5 kW
HO base load input current 22.8 A 28.6 A
HO base load output current 17.5 A 22.0 A
Fuse according to IEC
Fuse according to UL, class J
3NA3820 (50 A)
50 A
3NA3820 (50 A)
50 A
Power loss 0.2 kW
1)
0.26 kW
2)
Required cooling air flow 18.5 l/s 18.5 l/s
Weight without filter 5.0 kg 5.0 kg
Weight with filter 5.2 kg 5.2 kg
1)
approx. 0.2 kW through the heatsink
2)
approx. 0.15 kW through the heatsink
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
482 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
