Procedure
Proceed as follows to select the motor standard and system of units using STARTER:
1. Select in the "Configuration" project tree.
2. Select the "Units" tab.
3. Select the system of units.
4. Select the technological unit of the technology controller.
5. Select the technological unit of the additional technology controller 0.
6. Select the technological unit of the additional technology controller 1.
7. Select the technological unit of the additional technology controller 2.
8. Select the motor standard.
9. Save your settings.
10.Go online.
The inverter signals that offline, other units and process variables are set than in the inverter
itself.
11.Accept these settings in the inverter.
Advanced commissioning
6.15 Selecting physical units
Converter with the CU230P-2 Control Units
256 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
