Parameter Remark
p2291 CO: Technology maximum limiting (factory setting: 100 %)
p2292 CO: Technology minimum limiting (factory setting: 0 %)
Table 6-44 Manipulating the actual value of the technology controller
Parameter Remark
p2267 Technology controller upper limit actual value (factory setting: 100 %)
p2268 Technology controller lower limit actual value (factory setting: -100 %)
p2269 Technology controller gain actual value (factory setting: 100 %)
p2271 Technology controller actual value inversion (sensor type)
0: No inversion
1: Inversion actual value signal
If the actual value decreases with increasing motor speed, then p2271 must
be set = 1.
p2270 Technology controller actual value function
0: No function
1: √
2: x
2
3: x
3
For further information refer to the function block diagrams 7950 ff of the List Manual.
Table 6-45 Adaptation of gain and integral time
Parameter Remark
p2252 Technology controller configuration
.07 1 signal: Activating Kp adaptation
.08 1 signal: Activating Tn adaptation
p2310 Technology controller, Kp adaptation input value signal source (factory setting: 0)
p2311 Technology controller, lower Kp adaptation factor (factory setting: 1)
p2312 Technology controller, upper Kp adaptation factor (factory setting: 10)
p2313 Technology controller, lower Kp adaptation activation point (factory setting: 0 %)
p2314 Technology controller, upper Kp adaptation activation point (factory setting: 100 %)
p2315 Technology controller Tn adaptation scaling signal source (factory setting: 1)
r2316 Technology controller, Kp adaptation output
p2317 Technology controller Tn adaptation input value signal source (factory setting: 0)
p2318 Technology controller, lower Tn adaptation factor (factory setting: 3 s)
p2319 Technology controller, upper Tn adaptation factor (factory setting: 10 s)
p2320 Technology controller, lower Tn adaptation activation point (factory setting: 0 %)
p2321 Technology controller, upper Tn adaptation activation point (factory setting: 100 %)
r2322 Technology controller, Tn adaptation output
For further information refer to the function block diagrams 7958 and 7959 of the List Manual.
Advanced commissioning
6.18 PID technology controller
Converter with the CU230P-2 Control Units
276 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
