PM330 for pump, fan and compressor applications
Figure 3-3 PM330 for pump and fan applications
The PM330 Power Module is available as an unfiltered device. External line filters are available
as an option, see Section
Table 3-6 3-phase 380 VAC … 480 VAC, article numbers: 6SL3310-1PE…
Frame size GX HX JX
Power (kW) 160 … 250 315 … 400 450 … 560
Table 3-7 3-phase 500 VAC … 690 VAC, article numbers: 6SL3310-1PG…
Frame size HX JX
Power (kW) 315 … 450 500 … 630
Description
3.4 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 37
