Table 10-16 PM230, PT, frame size C, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3211-1NE23-8UG1
6SL3211-1NE23-8AG1
LO base load power 18.5 kW
LO base load input current 39.2 A
LO base load output current 38 A
HO base load power 15 kW
HO base load input current 33.1 A
HO base load output current 32 A
Fuse according to IEC / UL
Fuse according to UL, Class J
3NE1817-0
50 A
Power loss 0.45 kW
Required cooling air flow 18.5 l/s
Weight without filter 5.4 kg
Weight with filter 6 kg
Table 10-17 PM230, IP20, frame size D, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1NE24-5UL0
6SL3210-1NE24-5AL0
6SL3210-1NE26-0UL0
6SL3210-1NE26-0AL0
LO base load power 22 kW 30 kW
LO base load input current 42 A 56 A
LO base load output current 45 A 60 A
HO base load power 18.5 kW 22 kW
HO base load input current 36 A 42 A
HO base load output current 38 A 45 A
Fuse according to IEC / UL 3NE1818-0 3NE1820-0
Power loss 0.52 kW 0.68 kW
Required cooling air flow 80 l/s 80 l/s
Weight without filter 11 kg 11 kg
Weight with filter 14 kg 14 kg
Table 10-18 PM230, IP20, frame size E, 3 AC 380 V … 480 V
Article number without filter
Article number with filter
6SL3210-1NE27-5UL0
6SL3210-1NE27-5AL0
6SL3210-1NE28-8UL0
6SL3210-1NE28-8AL0
LO base load power 37 kW 45 kW
LO base load input current 70 A 84 A
LO base load output current 75 A 90 A
HO base load power 30 kW 37 kW
HO base load input current 56 A 70 A
HO base load output current 60 A 75 A
Fuse according to IEC / UL 3NE1021-0 3NE1022-0
Technical data
10.3 Technical data, PM230 Power Module
Converter with the CU230P-2 Control Units
450 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
