Property Version
Installation altitude Up to 1000 m above sea level without derating,
> 1000 m Restrictions for special ambient conditions (Page 510)
Climatic ambient conditions
1)
● Frame sizes FSD ... FSF temperature range
2)
– in operation acc. to LO: -20° C … +40° C
– in operation acc. to HO: -20° C … +50° C
– for higher temperatures
Restrictions for special ambient conditions (Page 510)
● Relative humidity: 5 … 95%, condensation not permitted
● Oil mist, salt mist, ice formation, condensation, dripping water, spraying water, splashing
water and water jets are not permitted
Mechanical ambient condi‐
tions
● Vibration levels permissible according to Class 3M1 to EN 60721-3-3
● Shock permissible according to Class 3M1 to EN 60721-3-3
Protection against chemical
substances
Protected according to 3C2 to EN 60721‑3‑3
Biological environmental
conditions
Suitable according to 3B1 to EN 60721‑3‑3
Pollution Suitable for environments with degree of pollution 2 according to EN 61800-5-1
Cooling Forced air cooling AF, according to EN 60146
Cooling air Clean and dry air
1)
Increased ruggedness regarding temperature range and relative humidity; therefore better than 3K3 according to EN
60721-3-3
2)
Observe the permissible ambient temperatures for the Control Unit and possibly the operator panel (IOP-2 or BOP‑2).
Technical data
10.4 Technical Data, PM240P-2 Power Module
Converter with the CU230P-2 Control Units
454 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
