Siemens CU240B-2 Operating Instructions

Article No. 6SL3310- 1PG33-7AA0 1PG34-0AA0 1PG34-5AA0
Recommended cable cross-section for 500 V
- DC link infeed (2/3 inverter power) 2 x 95 mm
2
2 x 120 mm
2
2 x 150 mm
2
Recommended cable cross-section for 690 V
- DC link infeed (2/3 inverter power) 2 x 95 mm
2
2 x 120 mm
2
2 x 150 mm
2
Tightening torque for line, motor, DC link, and
ground cable
50 Nm / 443 lbf in 50 Nm / 443 lbf in 50 Nm / 443 lbf in
Dimensions: Width x height x depth [mm] 548 x 1695 x 393 548 x 1695 x 393 548 x 1695 x 393
Weight 158 kg 158 kg 162 kg
Minimum control cabinet size for installation of the
Power Module (width x height x depth)
800 mm x 2000 mm x 600 mm
1)
The line supply must be capable of supplying the minimum short-circuit current so that the fuses trigger and consequential
damage is avoided.
Note: If the minimum short-circuit current is not reached, then the tripping time for the fuses increases, and this may result
in consequential damage.
2)
When semiconductor fuses are used, they must be mounted in the same higher construction as the inverter.
Table 10-34 PM330, frame size HX, 3-phase 500 … 690 VAC, Part 2
Article No. 6SL3310- 1PG35-2AA0
Rated input current
- at 500 V, 45 °C
- at 600 V, 45 °C
- at 690 V, 45 °C
- at 500 V, 55 °C
- at 600 V, 55 °C
- at 690 V, 55 °C
537 A
517 A
499 A
456 A
440 A
425 A
Rated input current DCP/DCN
(for 2/3 of the inverter power)
- at 675 V
DC
, 45 °C
- at 810 V
DC
, 45 °C
- at 930 V
DC
, 45 °C
- at 675 V
DC
, 55 °C
- at 810 V
DC
, 55 °C
- at 930 V
DC
, 55 °C
439 A
423 A
409 A
373 A
360 A
347 A
Rated output current I
N
- at 500 V, 45 °C
- at 600 V, 45 °C
- at 690 V, 45 °C
- at 500 V, 55 °C
- at 600 V, 55 °C
- at 690 V, 55 °C
516 A
497 A
480 A
438 A
422 A
408 A
LO base load power
LO base load input current at 690 V
LO base load output current at 690 V
450 kW
489 A
470 A
HO base load power
HO base load input current at 690 V
HO base load output current at 690 V
400 kW
410 A
394 A
Technical data
10.5 Technical data, PM330 Power Module
Converter with the CU230P-2 Control Units
472 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
