Siemens CU240B-2 Operating Instructions

Table 10-69 PM240-2, PT, frame size E, 500 V to 690 V 3 AC
Article No. without filter
Article No. with filter
6SL3211-1PH26-2UL0
6SL3211-1PH26-2AL0
LO base load power 55 kW
LO base load input current 59 A
LO base load output current 62 A
HO base load power 45 kW
HO base load input current 54 A
HO base load output current 52 A
Fuse according to IEC
Fuse according to UL, class J
3NA3824-6 (80A)
80 A
Power loss without filter 1.30 kW
1)
Power loss with filter 1.31 kW
1)
Required cooling air flow 83 l/s
Weight without filter 31 kg
Weight with filter 32.5 kg
1)
approx. 1.2 kW through the heatsink
Table 10-70 PM240-2, IP20, frame size F, 500 V … 690 V 3 AC
Article No. - without filter
Article No. - with filter
6SL3210-1PH28-0UL0
6SL3210-1PH28-0AL0
6SL3210-1PH31-0UL0
6SL3210-1PH31-0AL0
6SL3210-1PH31-2UL0
6SL3210-1PH31-2AL0
LO base load power 75 kW 90 kW 110 kW
LO base load input current 78 A 97 A 111 A
LO base load output current 80 A 100 A 115 A
HO base load power 55 kW 75 kW 90 kW
HO base load input current 66 A 85 A 106 A
HO base load output current 62 A 80 A 100 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3830-6 (100 A)
100 A
3NA3132-6 (125 A)
125 A
3NA3136-6 (160 A)
150 A
Power loss without filter 1.37 kW 1.74 kW 1.95 kW
Power loss with filter 1.38 kW 1.76 kW 1.97 kW
Required cooling air flow 153 l/s 153 l/s 153 l/s
Weight without filter 60 kg 60 kg 60 kg
Weight with filter 64 kg 64 kg 64 kg
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
500 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
