Braking resistors for PM240-2, 500 V … 690 V
Power Module Power Braking resistor
FSD 6SL3210-1PH21-4 . L0,
6SL3210-1PH22-0 . L0,
6SL3210-1PH22-3 . L0,
6SL3210-1PH22-7 . L0,
6SL3210-1PH23-5 . L0,
6SL3210-1PH24-2 . L0
11 kW … 37 kW JJY:023424020002
FSE 6SL3210-1PH25-2 . L0,
6SL3210-1PH26-2 . L0
45 kW … 55 kW JJY:023434020002
FSF 6SL3210-1PH28-0 . L0,
6SL3210-1PH31-0 . L0,
75 kW … 90 kW JJY:023464020002
6SL3210-1PH31-2 . L0,
6SL3210-1PH31-4 . L0
110 kW … 132 kW JJY:023464020002
Braking resistors for PM240-2, 200 V … 240 V
Power Module Power Braking resistor
FSA 6SL3210-1PB13-0 . L0,
6SL321 . -1PB13-8 . L0
0.55 kW … 0.75 kW JJY:023146720008
FSB 6SL3210-1PB15-5 . L0,
6SL3210-1PB17-4 . L0,
6SL321 . -1PB21-0 . L0
1.1 kW … 2.2 kW JJY:023151720007
FSC 6SL3210-1PB21-4 . L0,
6SL321 . -1PB21-8 . L0
3 kW … 4 kW JJY:02 3163720018
6SL3210-1PC22-2 . L0,
6SL3210-1PC22-8 . L0
5.5 kW … 7.5 kW JJY:023433720001
FSD 6SL3210-1PC24-2UL0,
6SL3210-1PC25-4UL0,
6SL3210-1PC26-8UL0
11 kW … 18.5 kW JJY:023422620002
FSE
6SL3210-1PC28-0UL0,
6SL3210-1PC31-1UL0
22 kW … 30 kW JJY:023423320001
FSF 6SL3210-1PC31-3UL0,
6SL3210-1PC31-6UL0,
6SL3210-1PC31-8UL0
37 kW … 55 kW JJY:023434020003
Description
3.5 Components for the Power Modules
Converter with the CU230P-2 Control Units
54 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
