Table 4-23 Dimensions depend on the operator panel (OP) that is inserted
1)
Frame
size
Width
[mm]
Height [mm] Mounting depth in the cabinet with
Control Unit (CU) [mm]
without shield
plate
with shield plate without OP with OP
1)
FSD 276 517 650 155 166
FSE 355 615 722 155 166
FSF 385 754 1021 193 204
1)
BOP-2, IOP-2 or blanking cover
Table 4-24 Cooling air clearances and additional dimensions
Frame
size
Power Module depth [mm] T1 T2 Cooling air clearances [mm]
Top Bottom Front
FSD, FSE 237 141 97.5 350 350 29
FSF 358 177.5 180.5 80 100 100
Table 4-25 Mounting
Frame
size
Fixing/torque [Nm]
FSD, FSE 10 × M5 / 3.5
FSF 12 × M6 / 5.9
Installing
4.3 Installing Power Modules
Converter with the CU230P-2 Control Units
82 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
