Commissioning
5.3 Quick commissioning using the BOP-2 operator panel
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
137
16.
Motor
data identification
Select the method which the inverter uses to measure the data of the
connected motor:
OFF
Motor data is not measured.
STIL ROT
Recomme
nded setting: Measure the motor data at
standstill and with the motor rotating. The inverter
switches off the motor after the motor data identification
has been completed.
STILL
Measure the motor data at standstill. The inverter
switches off the motor a
fter the motor data identification
has been completed.
Select this setting if the motor cannot freely rotate, e.g.
for a mechanically limited traversing range.
ROT
Measure the motor data while it is rotating. The inverter
switches off the motor after th
e motor data identification
has been completed.
ST RT OP
Setting the same as STIL ROT.
After the motor data identification, the motor accelerates
to the currently set setpoint.
STILL OP
Setting the same as STILL.
After the motor data identification,
the motor accelerates
to the currently set setpoint.
17.
Complete quick commissioning:
17.1.
Switchover the display using an arrow key: nO → YES
17.2.
Press the OK key.
You have completed quick commissioning.
