Backing up data and series commissioning
7.1 Backing up and transferring settings using a memory card
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
355
6. Select the settings as shown in the diagram and start the data backup.
7. Wait until STARTER signals that the data backup has been completed.
8. Close the screen forms.
You have backed up the settings of the inverter on the memory card.
Procedure with Startdrive
Proceed as follows to back up the inverter settings to a memory card:
1. Go online.
2. Select "Online & diagnostics".
3. Select "Backing up/reset".
4. Back up the settings to the EEPROM of the inverter.
5. Select the settings as shown in the diagram.
6. Start data transfer
7. Wait until Startdrive has signaled that the data backup has been completed.
You have backed up the inverter settings to a memory card.
